Harry Posted November 5, 2015 Share Posted November 5, 2015 I have read that one. It is a great read. QBO bible. Indeed. That also touches on enso as well. Also.. From that.. Decadal variability, possibly related to the 11-year solar cycle, clearly exists in data records which began in the 1950s. Labitzke [1987] and Labitzke and van Loon [1988] studied the observed late-winter NH circulation classified by both the level of solar activity and the QBO phase. They found a strong relation to the solar cycle during late winter. Naito and Hirota [1997] confirmed this relationship and found that early winter is domi- nated by a robust QBO signal. Figure 19 summarizes the solar-QBO results as scatterplots of mean 30-hPa geo- potential heights during January and February above the North Pole versus 10.7-cm solar radio flux (a proxy for the 11-year cycle in solar activity). The data set can be grouped into four categories based on the QBO phase and solar activity level. In years with low solar activity the polar winter vortex tends to be disturbed and weak when the QBO is easterly, but deeper and undisturbed when the QBO is westerly. In years with strong solar activity, however, westerly phases of the QBO are asso- ciated with disturbed winters, whereas easterly phases of the QBO are accompanied by deep and undisturbed polar vortices. Hence the QBO acts as predicted by Holton and Tan [1980] in years with low solar activity but appears to reverse its behavior during years with high solar activity. Only two cases do not fit this scheme: 1989 and 1997. Link to comment Share on other sites More sharing options...
Harry Posted November 5, 2015 Share Posted November 5, 2015 For those wondering what the QBO# is.. http://www.esrl.noaa.gov/psd/data/correlation/qbo.data -QBO is easterly and so the other is west which is what we have as Rainman said. Link to comment Share on other sites More sharing options...
Rainman Posted November 5, 2015 Share Posted November 5, 2015 Indeed. That also touches on enso as well. Also.. From that.. Ah, that must be paper that Camp 2006 debunked. At least that particular part of it. Link to comment Share on other sites More sharing options...
Harry Posted November 5, 2015 Share Posted November 5, 2015 Ah, that must be paper that Camp 2006 debunked. At least that particular part of it. You have a link to that? One of my peeves with that one i posted is them listing 98 as a QBO west? This says East----->http://www.esrl.noaa.gov/psd/data/correlation/qbo.data Guessing it was a accident? Link to comment Share on other sites More sharing options...
packbacker Posted November 5, 2015 Share Posted November 5, 2015 Indeed. That also touches on enso as well. Also.. From that.. Ah, that must be paper that Camp 2006 debunked. At least that particular part of it. Thanks for the link to that paper, still combing though it but Figure 19 is like a death knell to a SSW for this winter. We will most likely be below 100sfu with a westerly QBO and that combo is not good. Also explains last winter which was 150-160sfu with -QBO. Bummer.... Link to comment Share on other sites More sharing options...
Rainman Posted November 5, 2015 Share Posted November 5, 2015 You have a link to that? One of my peeves with that one i posted is them listing 98 as a QBO west? This says East----->http://www.esrl.noaa.gov/psd/data/correlation/qbo.data Guessing it was a accident? 97-98 winter was west, but 98-99 was east. Technically 98-99 transitioned to west at 30mb late, but that doesn't really seem sufficient to qualify the winter as +QBO. Here is the Camp & Tung abstract. Link to full article is there if you have access. http://journals.ametsoc.org/doi/abs/10.1175/JAS3883.1 Link to comment Share on other sites More sharing options...
Rainman Posted November 5, 2015 Share Posted November 5, 2015 FWIW, I have run some plots that suggest that a +QBO that completes downwelling early enough to transition the (top-bottom) shear to negative early in the winter favors a stronger polar vortex pretty strongly. In layman's terms, QBO winds start higher up in the stratosphere and move down over time. That's why the QBO is measured at 30mb and 50mb by CPC. Once the strong winds finish moving down (downwelling), the upper winds start to weaken...reverse...and start the process over again. Then the QBO changes phase as the next anomaly moves downward. Anyway, I think this month we'll probably get to the point where the QBO shear (not sure if that's what it's actually called, but that's what I'm calling it!) turns negative. In other words it will be stronger down low than they are up top. There is a physical significance to that, but don't understand it yet. But composites show that a +QBO entering negative shear during the winter favors quite a strong stratospheric PV. Link to comment Share on other sites More sharing options...
Powerball Posted November 5, 2015 Share Posted November 5, 2015 Of the top 20 warmest Novembers, the following winters had 7 snowier than normal winters, 2 winters with normal snowfall, and 11 winters with below normal snowfall. A friend (Adam from the other board) who is into nature signs says that all the nature signs are going absolutely bonkers for this coming winter to be on the harsh side. Sounds like JB lol. Extremists aside, the conflicting signals of this winter are crazy, as witnessed by the winter threads on these forums. Agreed. There are really no reliable analogs for this winter, which makes it even harder when trying to determine what to expect for this winter. Things have been marching to a brand new drum thus far. Link to comment Share on other sites More sharing options...
Harry Posted November 5, 2015 Share Posted November 5, 2015 97-98 winter was west, but 98-99 was east. Technically 98-99 transitioned to west at 30mb late, but that doesn't really seem sufficient to qualify the winter as +QBO. Here is the Camp & Tung abstract. Link to full article is there if you have access. http://journals.ametsoc.org/doi/abs/10.1175/JAS3883.1 Huh? 1997 -3.57 1.94 4.77 9.74 12.37 14.50 14.85 11.69 11.64 9.91 5.74 0.781998 -0.85 -2.96 -4.92 -7.82 -14.08 -18.57 -22.97 -24.70 -22.12 -18.77 -12.22 -3.96 Jan 98 was -0.85 and Feb was -2.96 which is a easterly QBO? Oh and thanks for the link up! Link to comment Share on other sites More sharing options...
michsnowfreak Posted November 5, 2015 Share Posted November 5, 2015 Agreed. There are really no reliable analogs for this winter, which makes it even harder when trying to determine what to expect for this winter. Things have been marching to a brand new drum thus far. Expect the unexpected needs to be the theme of this winter. Just a reminder too....it is absolutely plausible that a "warm" winter month for us could yield more, if not much more, snow than a "cold" winter month. The possibilities are endless. Link to comment Share on other sites More sharing options...
Rainman Posted November 5, 2015 Share Posted November 5, 2015 Huh? Jan 98 was -0.85 and Feb was -2.96 which is a easterly QBO? Oh and thanks for the link up! WTF, haha. Here are my QBO sources: 30mb http://www.cpc.noaa.gov/data/indices/qbo.u30.index 50mb http://www.cpc.noaa.gov/data/indices/qbo.u50.index I got +0.74 at 30mb and +5.13 at 50mb for JAN 1998. Link to comment Share on other sites More sharing options...
Harry Posted November 5, 2015 Share Posted November 5, 2015 WTF, haha. Here are my QBO sources: 30mb http://www.cpc.noaa.gov/data/indices/qbo.u30.index 50mb http://www.cpc.noaa.gov/data/indices/qbo.u50.index I got +0.74 at 30mb and +5.13 at 50mb for JAN 1998. Yeah.. I have been using this one.. http://www.esrl.noaa.gov/psd/data/correlation/qbo.data Link to comment Share on other sites More sharing options...
Rainman Posted November 5, 2015 Share Posted November 5, 2015 Yeah.. I have been using this one.. http://www.esrl.noaa.gov/psd/data/correlation/qbo.data Well then. CPC + ESRL = Link to comment Share on other sites More sharing options...
Powerball Posted November 5, 2015 Share Posted November 5, 2015 Expect the unexpected needs to be the theme of this winter. Just a reminder too....it is absolutely plausible that a "warm" winter month for us could yield more, if not much more, snow than a "cold" winter month. The possibilities are endless. Regardless of what the overall winter theme will be, I do think the chances are relatively high that our subforum will see a massive/moisture-laden winter storm at some point this season (speaking a once in a decade-type event), as the STJ is finally showing signs of life again. Link to comment Share on other sites More sharing options...
Harry Posted November 5, 2015 Share Posted November 5, 2015 Well then. CPC + ESRL = Link to comment Share on other sites More sharing options...
Chinook Posted November 5, 2015 Share Posted November 5, 2015 Well then. CPC + ESRL = CPC+ESRL= dancing tomato? I don't understand this equation. Link to comment Share on other sites More sharing options...
Rainman Posted November 5, 2015 Share Posted November 5, 2015 CPC+ESRL= dancing tomato? I don't understand this equation. It just felt right Link to comment Share on other sites More sharing options...
Geos Posted November 5, 2015 Share Posted November 5, 2015 I had a thread two winters ago on the QBO topic. Here: http://www.americanwx.com/bb/index.php/topic/38318-qbo-influence-on-our-winters/?hl=%2Bqbo#entry1983655 Upon researching the data myself I found a strong correlation between the "wintry" and the positive vs. negative phase of the QBO (Quasi-biennial oscillation). When the index (measurement taken at 30hPa) emerges from being in the deep negative side right before winter starts, the winter are usually a bit harsher or at least snowier than normal. Same goes if the index is positive going into winter. When the index is deep in the negative you tend to get benign winters ~ like 11-12. Right now we're quite positive, in a low solar stage, and with the dominating warm northern Pacific still. So I would go against el Niño ruling the roost on the weather pattern all winter long. As of October the index is 13.38. October of 2013 it was 11.69 for comparison. October of 2014 it was strongly negative at -23.86 and I think it weren't for the warm northern Pacific the Midwest winter would have been much calmer and/or milder than it was. I updated my chart showing the QBO index value at 30hPa and the ONI index. Thing about this winter is that we still have the same pattern in the northern Pacific with an el Niño - and we haven't seen that in our lifetimes. Link to comment Share on other sites More sharing options...
buckeye Posted November 5, 2015 Share Posted November 5, 2015 I wonder if this will be a winter of cut off lows. Deep sharp troughs cutting off in the midsection of the country and creating odd ball storm systems where you get snow to the south and rain to the north. Thinking of Feb '98 for instance. Link to comment Share on other sites More sharing options...
Hoosier Posted November 5, 2015 Author Share Posted November 5, 2015 I wonder if this will be a winter of cut off lows. Deep sharp troughs cutting off in the midsection of the country and creating odd ball storm systems where you get snow to the south and rain to the north. Thinking of Feb '98 for instance. That's kind of a hallmark of Nino. Link to comment Share on other sites More sharing options...
Hoosier Posted November 5, 2015 Author Share Posted November 5, 2015 Link to comment Share on other sites More sharing options...
Hoosier Posted November 5, 2015 Author Share Posted November 5, 2015 Link to comment Share on other sites More sharing options...
andyhb Posted November 5, 2015 Share Posted November 5, 2015 That's pretty ugly regarding possible weakening of the +PDO. Link to comment Share on other sites More sharing options...
Geos Posted November 5, 2015 Share Posted November 5, 2015 Very interesting, thank you for this. And I do think that is the thing.... On the bright side, in about 5 months we'll all have an analog to refer back to for that setup :-) That is very true! Found this interesting. Don't remember what the snowfall was like really well back during the 97-98 super Niño, but I do remember some snow. MKX posted this map of the departure of snowfall throughout the region. The snow belts suffered and the eastern corn belt, but everyone else was slightly under or even over normal snowfall. Link to comment Share on other sites More sharing options...
Hoosier Posted November 5, 2015 Author Share Posted November 5, 2015 Here's the whole snow season in 1997-98. Amounts and departures from average Link to comment Share on other sites More sharing options...
michsnowfreak Posted November 5, 2015 Share Posted November 5, 2015 summaryCFSv2.NaT2m.201512.gifFrom the beginning the cfs has been the torchiest model (nasa the coldest). It's nothing if not consistent. Someone in NE posted the cfs forecast for DJF from Nov last year...and let's just say it was WAY too warm.What is that second model you posted? It looks more like the jamstec. Link to comment Share on other sites More sharing options...
BuffaloWeather Posted November 5, 2015 Share Posted November 5, 2015 There is a strong coorelation between record warm Novembers and less overall snowfall in our region of the Great Lakes. Add to it a record strong El Nino and I'm going with an average of -20-25% average snowfall for the year with temp anamolies 2-4 Deg above average from Nov-March. Link to comment Share on other sites More sharing options...
Hoosier Posted November 5, 2015 Author Share Posted November 5, 2015 From the beginning the cfs has been the torchiest model (nasa the coldest). It's nothing if not consistent. Someone in NE posted the cfs forecast for DJF from Nov last year...and let's just say it was WAY too warm. What is that second model you posted? It looks more like the jamstec. From here: http://www.cpc.ncep.noaa.gov/products/people/wd51hd/sst/201510/carealtime.html Found it not that long ago. Don't really know much about it. By the way, if you have time, can you run the stats for Detroit as far as September, October, and November all being warmer than average (each month being +, not the Sep-Nov composite) and the following winter temperatures. Would be curious to see if there's any correlation as I found with Chicago. Link to comment Share on other sites More sharing options...
JoMo Posted November 5, 2015 Share Posted November 5, 2015 The SST CA forecast from Sept 2013, and Sept 2014 did pretty well for their respective (DJF) winters when it comes to temps. Precip wasn't that close but temp wise they had the right idea for the most part. Link to comment Share on other sites More sharing options...
michsnowfreak Posted November 5, 2015 Share Posted November 5, 2015 Locally there is a slight correlation to warm Novembers and below normal snow, but not a strong one. Longterm avg snow at Detroit ~41" Top 20 warmest Novembers and that winters snowfall 1931 – 26.2” 2001 – 33.7” 1902 – 51.3” 1975 – 55.9” 2011 – 26.0” 1963 – 32.5” 1948 – 13.7” 1994 – 33.5” 2009 – 43.7” 1999 – 23.7” 1964 – 49.2” 1909 – 46.8” 1953 – 40.0” 2003 – 24.1” 1883 – 50.3” 1990 – 31.4” 1946 – 30.0” 1998 – 49.5” 1934 – 32.2” 1960 – 18.0” Link to comment Share on other sites More sharing options...
